How to create and draw a new culture?

Attention!

Before you can apply these steps, you must first add a plot or a greenhouse.

More info can be found here:



Step - 1 Open Module Culture

On the left you will find the different modules. Here you will find the module culture. By clicking on it you will get several options under this button.



Step 2 - Open the overview of cultures

In the overview that is located under Culture, you will find the button Cultures. By pressing this you open the screen with an overview of all your cultures.


Step 3 - Add new culture

At the top of the list of all cultures, you will find the green button New culture. By clicking here you can create a new culture of a plot or a greenhouse. By making a choice you open the screen to create a new culture.


Indicate the correct plot/greenhouse and crop. Depending on the crop, you can select the corresponding planting system and then click Next.



Step 4 - Fill in general information


Before you start entering all the information, enter a Cultivation Name. This name gives you clarity about which cultivation it is exactly and is linked to a cultivation no. The latter is automatically assigned by the program.


At Plant date you enter the date when the crop was planted and the Plant system is automatically adopted based on what was selected in the previous POP-UP.








Step 5 - Indicate culture on map

First, locate your plot on the map.
Then indicate the vertices by clicking on the left mouse button. Do this in counterclockwise direction!

You can move a point by pressing the point with your left mouse button and moving the mouse to the correct place while keeping the left mouse button pressed.




USEFUL TIP

You can also designate separate rows.
Below is an example of what this might look like. Follow the numbers to
draw in the correct order.



On the right you will see that the Net Area is calculated automatically, but it can be adjusted manually. You can delete points by clicking on the red button Delete last point.



Step 5 - Enter culture data

Additional info:

The criteria are linked to the plant system and the crop. Because of this you will not always see all the criteria. You will see 3 tabs from which you can choose how you want to enter your data:

area, meter or number of plants.




Depending on which tab you have chosen, you will have to fill in some of the parameters below:



Net Area: The area of your culure alone.

Gross Area: The Net Area together with the headlands.

Path Width: The distance from the center of the row to the center of the next row.

Number/meter: The number of plants per meter.

Total running Meters: The total length of a row expressed in meters.

Total number of plants/trees: The total number of plants/trees present on the culture (number/meter x running meters).

Row width: Distance from the center of the row, to the center of the next row.

Plant distance: Distance between 2 trees in the length of the row.

Grass strip width: The width of the grass strip of 1 row.

Cultivation Free Zone: The cultivation free zone is an untreated strip of land near a body of water.

Spray factor: Value between 0-100%. This is the ratio of the height of the tree to the total height of the sprayer.

Row system: The number of trees per planting bed.



Also indicate whether or not following parameters are present on this culture:


Step 7 - Fill in certification

Here you can indicate any certifications. You do this by pressing the square next to the certification.


Step 8 - Enter main crop

Select the appropriate variety of the selected crop. Automatically it calculates the number of plants for this variety.



Step 9 - Save culture

When all data has been entered correctly, you can click Save at the bottom of the screen at Field data.
